Ascendant A26-17TJ

• Working Height: 26m

• Horizontal Reach: 17m
• SWL in platform: 280kg
• Platform size (1.1m high) tubular aluminium: 1.0 x 1.8 m
• Minimum vehicle GVW: 7500kg
• Typical wheelbase: 4400mm
• Stabiliser spread (full): 4.2m
• Spread in 1-side jacking mode: 3.2m
• Spread in narrow-jack mode: 2.2m
• Vehicle overall length: 8.82m
• Vehicle overall height: 3.6m

Specifications

• Working Height: 25m
• Horizontal Reach: 14.35m
• SWL in platform: 250kg
• Platform size (1.4m high) tubular aluminium: 0.7 x 1.1 m
• Minimum vehicle GVW: 3500kg
• Stabiliser spread (full): 3.3m
• Spread in 1-side jacking mode: 2.7m
• Spread in narrow-jack mode: 2.1m
• Vehicle overall length: 6.29m
• Vehicle overall height: 2.9m
