BLUELIFT SA 22

• Indoor work (atriums, galleries, malls, theatres, churches)
• Exterior jobs with restricted access (chimney repair, façade cleaning, rooftop gutters, tree surgery)
• Environments needing low noise and zero emission operation

• Working Height: 22m

• Lifting Height 20m
• Lateral Outreach 10,9m (200kg)
• Total Height 1,97m
• Total Width 0,94m
• Total Length 4,52m
• Basket Load 250kg
• Basket Size 1,3m x 0,7m x 1,1m
• Range of Rotation 340°
• Vehicle overall height: 3.6m
• Overall Weight 2990kg
• Travel Speed 1.5km/h
• Gradeability 28%
• Jack Widths 4,00m
• Jacking Length 4,85m

Specifications

Highlights

• Exceptional reach-to-weight ratio: 26 m high and 14.5 m outreach in a compact, 3.35 t package
• Tight access capabilities: <1 m width, sub-2 m height, adjustable tracks for confined spaces
• Versatile setup & power: Electric + petrol standard, optional hybrid/diesel; flexible outrigger positions
• Operator safety & comfort: Smooth proportional controls, multiple safety systems, remote diagnostics port.


• Working Height: 26m

• Lifting Height 24m
• Lateral Outreach 14,5m
• Total Height 1,98m
• Total Width 0,99m
• Total Length 4,91m
• Basket Load 250kg
• Basket Size 1,3m x 0,7m x 1,1m
• Range of Rotation 340°
• Vehicle overall height: 3.6m
• Overall Weight 3350kg
• Travel Speed 1.5km/h
• Gradeability 28%
• Jack Widths 4,44m
• Jacking Length 4,30m

Specifications

Featuring a single pantograph, a two-stage telescopic boom with jib, and mechanically adjustable tracks for both height and width, this versatile aerial platform delivers exceptional performance and impressive lateral outreach.

• Working Height 17,78m

• Basket Load 230kg
• +/- 178 °
  (356 ° non-continuous)
  Turret Rotation
• Lateral Outreach 11,15m
• Basket Size 1,4m x 0,7m x 1,1m
• Total Weight 2495kg
• Platform Height 15,78
• +/- 90 °
  (Optional Basket Rotation)
